Designing a Home Theater - Home Theater Remote - Choosing The Right Remote

What To Look For In A Home Theater Remote Control

Although it may not have been in your Home Theater Design, you will need a home theater remote control.

Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless you get a home theater remote.

There are a few different calibers of remote controls. If you only want to reduce the number of remote controls you have, then a basic universal remote would do the trick.

But, if you want a remote control that does more than control the A/V equipment, your choices will be slim.

Features like controlling lights and/or blinds. Or setting up macros/scenes which turn on and off various devices depending on the activity.

In this article, I’ll go over what I looked at when choosing my remote and how I set it up.

*PLEASE NOTE, SOME OF THESE LINKS ARE AFFILIATE LINKS. THAT MEANS IF YOU CLICK ON ONE OF THE PRODUCT LINKS, WE’LL RECEIVE A SMALL COMMISSION AT NO EXTRA COST TO YOU. IT HELPS SUPPORT THIS BLOG AND ALLOWS US TO KEEP SHARING OUR CONTENT FOR FREE. AS AN AMAZON ASSOCIATE I EARN FROM QUALIFYING PURCHASES.

Why Not Just Use The Remotes You Have

Choosing the right remote control will completely change your home theater experience. A typical home theater will have at least 3 remotes (for the TV/Projector, surround sound, Cable box or DVD Player).

Fumbling between all the remote becomes a pain pretty quickly. Many of the remotes that come with home theater equipment do try to be universal-ish. But they still fall short with home theater scenarios.

The Remote Criteria

The remote I was searching for would control:

  • the projector
  • The surround sound amplifier
  • 4K BluRay DVD player
  • The Cable Box
  • Some way of controlling Insteon lights
A Home Theater Remote that can control all that is pretty sophisticated. And the more features a remote has, the more expensive it gets.

On the low end, they are about $100. These remotes will have a low limit on the devices that can it can control and no macros. On the super fancy high end, there is a complete home automation system. That system can control just about any electronic device, but of course, it’s at a cost. The Savant is one of those systems and runs about $1000 a room.

For my scenario, I already have a home automation system so Savant wasn’t something I had any interest in.

My home automation system is an Insteon based system. A Universal Devices ISY controller (Model ISY 994i/IR Pro) that controls everything. Things like the door lock, the thermostats, lights, and door sensors.

Logitech Harmony Ultimate Home

After some research, it became clear the Harmony family of remotes is the best value for the features. They’ve been in the remote control business for a very long time and they have excelled over the years.

Which a Harmony remote, you base your choice on how many devices you plan on controlling. The Harmony remote I chose was the Ultimate Home. It can control up to 15 devices with up to 15 activities. The activities are basically macros. Press one of the macro buttons, and it’ll turn on all the devices you need turned on for that activity.

Update:  The remote that I chose is now discontinued. The Logitech Harmony Elite Remote is the latest home theater remote from Logitech. It looks a little different but the specs are very similar.

An added bonus is that the Harmony Elite Remote also works with Alexa!

Designing a Home Theater - Home Theater Remote - Logitech Harmony Elite Remote

Logitech Harmony Elite

Logitech Harmony Elite Remote Control, Hub and App, works with Alexa

Logitech Harmony Home Ultimate Features

The Harmony Home Ultimate (and the Harmony Elite) is a feature-rich remote control.

  • The Harmony App On your Droid or iPhone lets you control your devices using the app
  • Configure macros or activities to set up all your devices with a click of a button
  • Control up to 15 Devices
  • Control devices using infrared, IP and Bluetooth
  • It Syncs the cable providers channel line up with your remote. When the cable provider changes channels around your remote will update itself
  • Save your favorite channels as favorites, which show up as icons in the remote’s screen
  • a digital screen on the remote allows you to customize buttons and activities
  • The hard buttons are all back-lit (very important when you are sitting in a dark theater)

The Parts To The Home Theater Remote Control Setup

There are three physical parts to the remote control. The remote control itself, a Hub and infrared blaster cables.

The hub is the brains of it all, and the remote control communicates to the hub using RF (radio). It’s great for home theater setups like mine, where the AV equipment is in a closet out of sight.

The hub should go where the majority of your electronics are since it’s the one doing most of the controlling.

The AV Equipment

In this setup, there’s a total of 6 devices listed in the MyHarmony app:

  • Universal Devices ISY-994i/IR (Home Automation)
  • Yamaha TSR-7810 (Amplifier)
  • Epson PowerLite Home Cinema 5040UB (Projector)
  • Arris DCX3600M (Cable/DVR)
  • Panasonic DMP-UB900 (4K BluRay Player)
  • Windows Computer

Setting Up The Remote For Your Home Theater

Harmony has done a great job with their remote controls. The basic initial setup was pretty straight forward.

You’ll need to install their MyHarmony software and run the setup. You can either install it on your PC or on your phone and it will guide you through the setup process.

During setup, the hub was able to automatically detect the Yamaha amplifier on the WiFi.  For the other devices (cable box, DVD player and projector) I needed to supply the make an model.  Based on the make an model, it knew the full set of remote codes for them.

Much easier than the old days where you had to teach your universal remote the codes for each function.

A Home Theater Gotcha

If you have a theater like mine, you have AV equipment tucked away in a closet close by but out of sight.

The Harmony Hub goes in the closet along with all the AV equipment, but one gotcha is the projector.

Initially, I wasn’t sure if I’d have to run one of the infrared blasters into the theater to get it to turn on/off the projector.

Well, luckily Harmony had already thought of that. In the MyHarmony App, you determine what controls the device, either the remote or the hub.

That’s done here:

  • Go to the MyHarmony App and click settings
  • Click More >>
  • Remote and Hub Assignments

Problem solved.

Update:  The solution above worked great, but it would only work if you were in the room to turn on the projector. I sometimes use the MyHarmony app on my phone to turn the theater equipment on or off from outside the room.


Since the remote controlled the projector, the projector didn’t turn on. In

the end, I ran one of the IR blasters from the Harmony hub to the theater, and that worked like a charm.

Getting Harmony To Talk To Insteon

Like I said earlier, my home automation is Insteon based. When I was setting up my home theater I expected to one day be able to control the lights. And maybe even the curtains using my home theater remote control.

Insteon has a user-friendly device called InsteonHub, which Harmony can communicate with natively.

My setup uses a Universal Devices controller, which is more flexible but not as user-friendly. Initially, it didn’t seem obvious how I could get Harmony and Insteon to talk to each other.

At first, I thought I’d have to use some sort of Rest based commands to control the lights using the Harmony remote.

During my googling, I did see something using a Raspberry PI and something called ISY Helper to do just that.

From what I understand, the ISY Helper is the go-between for the Harmony and your ISY.

For my setup, it sounded like way too many moving parts.

Luckily the ISY I purchased had infrared, I think you can also buy the add-on module for the ISY if your ISY doesn’t have IR.

What Insteon Devices Can You Control With Harmony

With the Insteon Hub, I think you can only control the lights. With the infrared module in the ISY, you can control everything that the ISY can control.

On the ISY you would create a program with the things you want the ISY to do. Then assign that program to an IR code.

Let’s say you want to set the temp at a certain level, dim the lights in the theater and lock the front door for the evening.

Create a program with those steps and assign it to an IR code. Now create an activity on your remote that sends that IR code, you’re all set!

Pretty cool! And you have no limit to the possibilities.

Actually, you only have 40 IR codes to play with. But each of those codes can be configured to do a whole lot on the ISY side.

Add ISY To The Remote

Adding the ISY to the remote was straight forward. Add a new device in the Harmony app. And use Universal Devices as the manufacturer and ISY994i/IR as the model number.

As soon as you do that it will add the 40 infrared codes that the ISY uses into the remote.

Setup On The ISY

To add the IR codes on the ISY side was just as easy. Go into the admin console, click the IR tab and click the ‘Import Default IR Codes’ button. That adds the same 40 infrared codes into the ISY.

Using You ISY From The Remote

I wanted to be able to turn off/on Insteon lights using the remote control. Both within Harmony activities and independent of the activities.

To add your ISY IR commands on the remotes menus click the buttons option in the MyHarmony app.

Under ‘Screen Options’ select your ISY device, in my case, I called it Lights. and click Go.

Here you can add soft buttons for each IR command you would like to control directly from the remote.

Here’s a list of my configured soft buttons under Lights:
  • High Hat On
  • High Hat Off
  • Screen Light On
  • Screen Light Off
  • Stair Light On
  • Stair Light Off
  • Loft Dim/Off

The ISY Listed as a device on the remote

Designing a Home Theater - The Fixed Projector Screen - The Edgeless Screen
Designing a Home Theater - Home Theater Remote - Logitech Harmony Elite Remote - The Digital Screen with the ISY Commands Listed As Soft Buttons

High Hat Off Program In ISY Admin Console

Designing a Home Theater - Home Theater Remote - Logitech Harmony Elite Remote - ISY Program To Turn Off The High Hats

Setting Up Harmony Activities

This is where the really cool functions of the remote control start to shine.

With the Harmony remote you can set up activities. Activities are basically macros with functions for any of your configured devices.

An example of an activity that I have set up is “Watch TV”. When I press the button for that activity it does the following:
  • Powers on the projector
  • Sets the projector input to HDMI1
  • Powers on the amplifier
  • Sets the amplifier input to HDMI2
  • Powers on the Cable/DVR
  • Turns of the lights in the Movie Theater

When you are done watching TV and want to turn everything off, just press the button next to the activity again and it’ll turn everything off.

Now if you have a home theater and don’t yet have a remote control with macros, I think you can appreciate how this remote can have everything on, set and ready to go with the press of one button.

No more fumbling with every remote control you have to get things set up just to watch TV.

Before Harmony these were my steps:

  • Get the projector remote, press the power button
  • Get the amplifier remote, press the power button and set it to HDMI2
  • Get the Cable remote, press the power button
  • If the lights were on, get up and press the button to turn them off

A big difference in user experience.

In a way, the remote control is the mortar in the electronic building blocks of your home theater. It changes your experience completely.

Tweaking The Activities

MyHarmony has a GUI that helps you create activities in a pretty intuitive way. To set up a basic activity is not very difficult, it’s just a matter of following the prompts.

Once the activity has been created the software will ask you to test the activity. I’d say the majority of what it sets up works pretty nicely.

Activities need tweaking with devices that take a long time to turn on or if it uses cursor commands. An example would be clicking left once then up then enter.

No matter how complex the activity, after a bit of tweaking things will work pretty reliably.

Below are my activities along with their settings.

My Activities List

Here are all my configured activities and settings. The “Lights – IR004” entry triggers the “Turning off the Movie Theater lights” program on the ISY.

The Watch Amazon activity is an example of an activity using cursor movements. The DVD Player has no built-in button for Amazon so I used cursor movements to select the AmazonApp.

I also added mute at the beginning and the volume down at the end because of an annoying ding sound the DVD player made. Every time the cursor in the interface moved there was a ding, and I didn’t like hearing it.

Watch TV

  1. Projector – Power On
  2. Projector – Input HDMI 1
  3. Amplifier – Power On
  4. Amplifier- Input HDMI 2
  5. Cable DVR – Power On
  6. Lights – IR004

Watch A Movie

  1. Projector – Power On
  2. Projector – Input HDMI 1
  3. Amplifier – Power On
  4. Amplifier- Input HDMI 2
  5. Cable DVR – Power On
  6. Lights – IR004

Watch Netflix

  1. Blu-Ray Player – Power On
  2. Amplifier – Power On
  3. Amplifier – Input: HDMI 1
  4. Projector – Power On
  5. Projector – Input: HDMI 1
  6. Wait 10 sec
  7. Blu-ray Player – Netflix
  8. Lights – IR004

Watch Amazon

  1. Amplifier – Power On
  2. Amplifier – Input: HDMI 1
  3. Blu-Ray Player – Power On
  4. Projector – Power On
  5. Projector – Input: HDMI 1
  6. Wait 15 sec
  7. Amplifier – Mute
  8. Blu-ray Player – Internet
  9. Wait 14 sec
  10. Blu-ray Player – DirectionLeft
  11. Wait 2 sec
  12. Blu-ray Player – DirectionDown
  13. Wait 2 sec
  14. Blu-ray Player – OK
  15. Amplifier – VolumeDown
  16. Lights – IR004
Designing a Home Theater - Home Theater Remote - Logitech Harmony Elite Remote - The Digital Screen with the Activities List

Summing It All Up

Having a Harmony Home theater remote control is way better than trying to manage 6 remotes…. but I had no idea how much better the experience was going to be.

The remote control makes it a real pleasure to turn on and off your devices. If you have a home theater getting a Harmony remote control is a must!

The simplicity of use that a remote like this gives you is amazing.

In my opinion, a home theater design is incomplete if it doesn’t include a home theater remote control.

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...

Home Theater Design – The Video Projector

Home Theater Design – The Video Projector

Designing a Home Theater - The Video Projector This is the Epson Home Cinema 5040UB. A fantastic projector that does 4K, HDR 10 and Ultra-wide DCI-P3

What I Was Looking For In A Video Projector

One of the main choices when designing a movie theater (and potentially the most expensive) is the video projector.

I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector with internet apps (like Netflix), 3D would be nice, multiple HDMI inputs and an image that wasn’t washed out. Because my movie theater has a couple of windows, I wanted something that would still be watchable with sun coming into the room.

Since I had never looked into projectors before I was really shocked to see how high prices for projectors go. I mean the higher end projectors are, I mean a lot of the higher priced stuff is in the $25,000 – $30,000 range.

I was not looking to spend anywhere near that amount, but I did want a really nice projector. After seeing those initial prices, I kind of felt like maybe I wasn’t going to be able to spring for a nice projector after all. Realistically I was expecting to spend around $2,000 maybe up to $3,000.

Luckily there are a few projectors out there that give you great value without breaking the bank.

I wrote this article hoping to help others not feel as overwhelmed as I did when doing projector research for their movie theater.

*PLEASE NOTE, SOME OF THESE LINKS ARE AFFILIATE LINKS. THAT MEANS IF YOU CLICK ON ONE OF THE PRODUCT LINKS, WE’LL RECEIVE A SMALL COMMISSION AT NO EXTRA COST TO YOU. IT HELPS SUPPORT THIS BLOG AND ALLOWS US TO KEEP SHARING OUR CONTENT FOR FREE. AS AN AMAZON ASSOCIATE I EARN FROM QUALIFYING PURCHASES.

What I Learned About Video Projectors

So in doing my research, I learned a bunch. It’s hard to remember every aha moment, but I’m gonna give it a whirl, here are some of my aha moments.

The Projector Doesn’t Need Multiple HDMI Inputs

Originally I thought the video projector I was looking for needed multiple HDMI ports. I was looking for about 4. One for the cable box, DVD player, gaming console and PC.

Turns out if you’re designing a home theater, chances are you will be installing a surround sound system.

When using a home theater system, it has plenty of HDMI inputs and you use the home theater system to control the inputs.

In my scenario it made things much easier. I only needed to run one 20 foot HDMI cable from the surround sound system to the projector, all the other HDMI devices were in the same closet as the surround sound system so I could use regular length HDMI cables.

Designing a Home Theater - The Video Projector - The HDMI Cable Layout

Video Projectors Are Not “Smart”

One of my initial requirements was that the project had internet apps. What I found out was that projectors are not really like smart TVs, they’re more like computer monitors… that project the image on the wall.

All the projectors I looked at did not have any “smart” capabilities. So to get NetFlix, Hulu, Amazon etc you need to plug something into the projector that has “Smart” features.

How To Get 4K Content On Your Projector

In my setup, I purchased an Ultra-HD Blu-ray player that had internet apps. The Blu-ray Player is a Samsung UBD-K8500 Ultra HD Blu-ray Player that does 4K and has built-in WiFi.

Update: In trying to figure out a problem I was having with 3D content, I purchased a Pioneer UB900 Ultra HD Blu-ray Player. The Blu-ray Player didn’t fix my 3D problem (my problem was a defective projector – which Epson quickly fixed). But the difference in sound between the two players was big enough that I decided to keep the Pioneer UB900.

The Ultra-HD is vital if you want 4K content from Netflix. If you upgrade your subscription and you are watching Netflix on a 4K capable device, Netflix will have an addition 4K category.

How To Get HDR Content On Your Video Projector

Here’s something I was not aware of.  I figured if it were a Blu-ray DVD, it would play in HDR. That was not correct at all.

To have HDR content play on your projector, first, all the equipment that is playing the DVD will need to be HDR compatible (projector, DVD player, Amplifier).

And second, you’ll need a DVD that is Ultra-HD, not just Blu-ray.

It’s easy to figure out if the DVD is Ultra-HD. On the top of the face of the DVD case it’ll say 4K UltraHD – usually in silver on a black background.

Here’s a link from Netflix with the details on how to get 4K content:

This article contains information about watching Netflix in Ultra HD on compatible devices.

Designing a Home Theater - The Video Projector - Epson Home Cinema 5040UB

Projector Picture Quality

Aside from the option of 1080p and 4K, there are two other things that contribute to the picture quality. The image brightness (measured in lumens) and the contrast ratio (the difference between the whitest white on the screen and the blackest blacks on the screen).

It’s All About The Lumens

The lumens was something that was a factor for me since I was going to have some ambient light in the room. I was also expecting that there would be times where I’d like to watch content with the lights in the room on.

Just about all the projectors I looked at were 1000 lumens or brighter which from what I had read was a pretty decent brightness.

The Contrast Ratio Is Where It’s At

My impression of projectors has always been that the picture was always washed out. I wanted to have something that would do a good a job as possible in minimizing the washed-out image.

What I found out was that the biggest factor in preventing the washed-out image is the contrast ratio.

As far as contrast ratio goes, it seemed like those were all over the map.

My Updated Video Projector Criteria

After doing a bunch of research on the different factors that make a good projector and finding out some of my original criteria were no longer criteria at all. I now knew what I had to focus on.

My Updated Criteria

  • at least one HDMI input
  • no longer needed to be “smart”
  • it needed to at least be 1080p (native 4K looked way out of my price range)
  • Finally, the primary focus was a projector with as high a contrast ratio as possible (to prevent that washed out image)

Choosing The Best Projector For The Money

I looked at a lot of projectors. Ranging from around $700 all the way up to $27,000 (some are even 4 times that price but 27k was a crazy enough price for me).

For $700 you get a projector that is small and portable with a very small foot-print.

For $27,000 you could get a top of the line Sony 4k projector.

I wanted to get the biggest projector screen that I could fit on my wall. Since it was going to be a good-sized screen, I wanted to make sure the projector was at least HD (1080p).

4K would have been fantastic, but $27,000 was way, way, way out of my budget.

Once I narrowed down what I was looking for the best choice for me started to float to the top.

Now I was confirming that there was no other projector that was better than what I found for the money…. and there wasn’t!

Designing a Home Theater - The Video Projector - Epson Home Cinema 5040UB 3LCD Home Theater Projector with 4K Enhancement

My Video Projector – Epson Home Cinema 5040UB

Epson Home Cinema 5040UBe WirelessHD 3LCD Home Theater Projector with 4K Enhancement, HDR10, 100% Balanced Color and White Brightness, Ultra Wide DCI-P3 Color Gamut and UltraBlack Contrast

The Projector That I Chose – Hands Down The Best For The Price

After a lot of searching, there was one projector that stood out of the crowd. The Epson Home Cinema 5040UB is the projector that I went with.

It had fantastic reviews, does 1080p, 3D, HDR with a 1,000,000:1 contrast ratio and it even does 4K emulation – all for $2,499! The 4K emulation means it supports 4K input and will do some fancy stuff to project it in 4K-ish quality.

When I first started my search, I thought I’d have to stick to 1080p, since 4K was way out of my budget. Although the projector doesn’t do true 4K, 4K emulation made it way better than any other projector – even at twice the price.

The 1,000,000:1 contrast ratio and 4K emulation were the two determining factors for me. The other of course was the oodles and oodles of positive reviews for it.

It’s been about a month that I have owned one and I can tell you that the picture is absolutely astounding.

I would love to see what a native 4K projector picture quality looks like. It’s hard for me to imagine that there can be a better picture than what the Epson 5040ub produces.

I find myself often forgetting that it’s a projected image, it really just feels like a 135″ TV screen!

The Epson 5040UB or Epson 5040UBe

There are two models of this projector, the one I purchased is the Epson Home Cinema 5040UB.

The other model is the Epson Home Cinema 5040UBe, which has a wireless ethernet adapter for wireless HD, allowing you to have content streamed wirelessly to the projector.

I didn’t go for the wireless option since it was $300 more, and since I was going into the attic to run speaker wires anyways running an extra HDMI cable wasn’t a big deal.

3D On The Epson Projector – The Problem

3D wasn’t a terribly important criteria for me in my projector choices, but since the Epson projector supported 3D, it was a nice perk. 🙂

The projector doesn’t come with 3D glasses so when you’re ready for 3D, you’ll need to buy the glasses separately.

I’ll write up a separate article on my 3D glasses research later, this part though is crucial if you bought your projector around the same time I did – April 2017.

I’ll just cut to the chase and spare you the details but after trying different glasses, DVD players and cables – the problem ended up being the projector.

I had to look through tons of forum posts to find a new thread where others had a similar problem. They suggested to contact Epson, and they would take care of it. I did just that, and they sent me a brand new projector the very next day.

If you have an Epson projector and the 3D images don’t knock your socks off, contact Epson. Chances are you have a defective projector, and their customer service is fantastic and responsive.

If you are in the US, then you can send an email to [email protected], that’s where I sent my email, and they responded by the end of the day.

More Picture Quality Samples

Designing a Home Theater - The Video Projector - Epson Home Cinema 5040UB Picture Quality No Lights  The picture quality without lights on in the room and some ambient light still coming in. The image is from a Netflix 4K nature show.
Designing a Home Theater - The Video Projector - Epson Home Cinema 5040UB Picture Quality No Lights  The picture quality without lights on in the room and some ambient light still coming in. The image is from a Netflix 4K nature show.

The Video Projector Mount

I’m not sure if there are differences in projector mounts. I just made sure the one I bought was compatible with the Epson 5040UB.

The projector mount I chose was the Universal Projector Mount Bracket.

I have a feeling that most mounts would work with most projectors, but I wanted to make sure I wasn’t going to have a problem with it.

This mount definitely works, although if I had to do it again, I probably would have gotten on that was a bit more sturdy.

Don’t get me wrong; If your projector is going to be out of reach of most people, then this mount will work out perfectly.

In my case, since I have the raised platforms, the projector does stand a chance of getting bumped by someone who is tall and not paying attention to where they’re going. 🙂

The projector won’t fall or anything, but if it’s a substantial bump, it may shift a little requiring a readjustment of the projector image on the screen.

Designing a Home Theater - The Video Projector - The Video Projector Mount

The Video Projector Mount

Projection Screen LED KIT 2018 Version (135-inch Diagonal Screen, 16:9 Aspect Ratio)

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...

Home Theater Design – The Fixed Projector Screen

Home Theater Design – The Fixed Projector Screen

Designing a Home Theater - Home Theater System - Choosing A Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy.

Here I’ll go over what options there are in projector screens and why I went with a fixed projector screen.

*PLEASE NOTE, SOME OF THESE LINKS ARE AFFILIATE LINKS. THAT MEANS IF YOU CLICK ON ONE OF THE PRODUCT LINKS, WE’LL RECEIVE A SMALL COMMISSION AT NO EXTRA COST TO YOU. IT HELPS SUPPORT THIS BLOG AND ALLOWS US TO KEEP SHARING OUR CONTENT FOR FREE. AS AN AMAZON ASSOCIATE I EARN FROM QUALIFYING PURCHASES.

What I Was Looking For In A Fixed Projector Screen

Honestly, The projector screen in my head wasn’t as important initially.

After doing a little research I soon realized that the projector screen has a lot to do with how crisp the picture is going to be. Like I mentioned in the article about the projector, the crispness is something I was really looking for.

My impression of projectors has always been a very washed out image that was hard to see unless the room was completely dark. I really wanted to minimize that effect as much as possible with my setup.

Since my movie theater has windows ambient light was going to be some sort of factor, and I expected that I would sometimes want to watch TV with the lights on.

Little did I know that choosing the right projector screen would have a big inpact in crispness.

The Different Types Of Projector Screens

If you’ve done any sort of research in projector screens, then you know there are a ton of choices when it comes to projector screens.

Aspect Ratio

There are two basic aspect ratios for screens 4:3 and 16:9. The easy way to think about it is that 4:3 is an old TV format (more like a square) and 16:9 is the new flat screen TV format (a long rectangular shape).

No brainer for me, I wanted 16:9 since that is kind of the new standard in our days.

Designing a Home Theater - Home Theater System - Screen Aspect Ratios

Retractable or Fixed Frame

Retractable projector screens are the ones you can pull down, similar to what you find in school. The other option is a fixed frame projector screen. In my case the room is a dedicated movie theater, so there was no need for my screen to retract.

They say the picture quality is better on a fixed frame because there is much less movement.

Designing a Home Theater - The Fixed Projector Screen - A Retractable Screen
Designing a Home Theater - The Fixed Projector Screen - Elite Screens - A Fixed Projector Screen

The Screen Color – White, Gray Or Black

This was something I never thought of or heard about. I’ve always seen Projector screens in white, apparently they come in gray and black too.

I didn’t understand the differences at first but after a little research it made perfect sense.

the projector can not project black, so having a darker screen essentially increases the contrast ratio (the difference between the whitest whites and the blackest blacks on the screen).

A black screen will give you the best contrast ratio while a white would be the worst. Black screens are also much more expensive. I went with grey, it’s the middle ground for both contrast ratio and price.



Front Lit Or Back Lit Screens

If you have the space you can have a back lit screen, meaning that the projector is behind the screen.

In my case I wanted to use all the real estate I had for the movie theater so I stuck to a front lit screen.

Edged or Edgeless

There are screens with a border around it giving it a more traditional look, or there are screens that are edgeless – meaning the picture can go all the way to the edge of the screen.

When I started looking at screens this wasn’t much of a concern for me. I had seen edged and edgeless screens that looked great.

Acoustic Projection Screen or Not?

Now this is something I may have chosen if I had more space to put speakers behind the screen. The acoustic screen allows sound to pass through it, that way the center speaker and left and right surround sound speakers can be placed behind the screen.

It would have made for a really nice look, but since ambient light was more of a concern for me than placing the speakers behind the screen I decided to focus on a screen that would work will with ambient light.

What Screen Size?

This was a bit of a tough one. I wanted the biggest screen I could fit on my wall, so I was limited in screen width by the width of the wall minus the width of the left and right surround sound speakers.

I was limited in height by the height of the wall minus space on top for the infrared repeater, minus the height required to see the bottom of the screen from the back row.

Since I had already figured out what my projector was going to be I could figure out the screen size using this amazingly helpful calculation tool.

Screen Size Calculator

Click this button to go to the site I used to determine what screen size to use in the room.

It bases it on the video projector along with the projector placement in the room.

Since I knew the model projector it helped not only determine the size of my screen, it also helped me figure out where on the ceiling my projector should be mounted.

Using the tool I was able to decide on the 135″ screen and that the projector was going to be 178″ away from the screen wall.

The Best Looking Fixed Projector Screen

The first non-white screen I came across was the Black Diamond screens. Holy cow it looked sexy!

Basically when the projector is off you have a black screen on your wall, like a huge flat screen. This is definitely the screen I would have gone with if price was no object – for me though it was.

The black diamond screen would have cost me more than the Epson 5040UB. Way too much for me to spend.

Now I Looked For The Best Value For My Money

Since the black diamond did not fit into my budget at all, I needed to find something close to it that fit into my budget.

I really didn’t want to spend more than $1000 for my screen, so that was the limit I set for myself.

I came across the Elite screens and it seemed to be a reputable screen manufacturer. They screens they had also fit my budget.

I ended up deciding that Elite screens was the brand I was going to buy and looking at the different types of screens they offered to see which was best for me.

The screen I ended up choosing was the Aeon 135″ 16:9 ambient light rejecting ALR Fixed Frame Edge Free Projection screen, model # AR135DHD3

The Fixed Projector Screen I Chose

Like I said earlier, your speaker budget will be the driving force behind your home theater system decision.

In the end, I found a great price on a set of 7.2 speakers, so I knew I could start looking for a Dolby 7.2 home theater system.

The amplifier I ended up going with is the Yamaha TSR-7810 7.2-Channel Network Receiver, which I purchased online.

It had great reviews and more than enough features for my setup at a reasonable price.

The amplifier has 7.2 channel surround sound, DTS:X, Dolby Atmos, the 4K HDR passthrough and support for 3D. It met all the criteria from my list, and it was also a reasonable price.

Click To Get The Same Home Theater System - Yamaha TS-R7810

The Projector Screen I Chose

Elite Screens Aeon CineGrey 3D Series, 135-inch 16:9, Ambient Light Rejecting Fixed Frame Edge Free Projection Projector Screen, AR135DHD3

The Edgeless Fixed Projection Screen

The back bevel on this fixed projection screen gives it a clean, snazzy feel.

The picture on the right shows how the screen with an image projected on it. I love how the image goes all the way to the edge.

Designing a Home Theater - The Fixed Projector Screen - The Edgeless Screen
Designing a Home Theater - The Fixed Projector Screen - The Edgeless Screen

Why I Chose This Screen

I chose this screen because it got great reviews and it was specifically designed for rooms with ambient light. The specs also mentioned that it would work with 3D movies, which I was planning on using.

The screen is a edge-less screen which means you can project the image all the way to the edge of the screen for a really impressive display. Having a edge-less screen gives it the feel off a gigantic flat screen TV.

If you prefer a frame around the screen, they also provide felt tape that you can put around the edge. Giving it more of a traditional TV feel. I personally like having an image that takes the entirety of the screen.

Assembling The Screen

Assembling the screen was a little tricky. I read reviews on it that said to be careful of the sharp metal edges on the frame, and I can see why.

It takes quite some doing to get the screen material to stretch to the point where it will cover the frame. Once you work with the screen material a little you’ll realize that it does have a good amount of give… you just want to take your time with it.

We basically started from the short side first, connecting the screen to the very edge of the Velcro on the frame. That was the hardest part.

Once we had one small section connected on both ends it was a matter of working your way around the frame. As you make your way around it gets easier and easier to get the Velcro to connect.

Optional Back-Light Kit

A Nice Touch… Back-light

The screen also has this Optional LED back-light kit, which made for an incredibly sexy look.

I purchased the kit straight from Elite screens since they didn’t have the 135″ model available on Amazon.

Installing The Optional LED Back-light Kit

A Nice Touch… Back-light

The back-light kit model number for the 135″ screens is ZLED135H1.

Installing the back-light was pretty straight forward. Start by figuring out where you want the power plug for the lights to be, that will be your starting point.

Put the screen face down on the floor, starting where you want the power plug to be remove the sticky tape covering and stick the lights to the angled back part of the screen.

You’ll have a little extra once you go around the screen, just cut the strip on the indicator lines they have every couple of inches.

One thing to be aware of is that the light strip is pretty sensitive to bending. Be gentle and careful not to kink the strip and when doing the corners try to round the corner – avoid sharp angles.

The backlight was worth it, it gives a great finish to the screen. My favorite light setting is on low light with white light.

Designing a Home Theater - The Fixed Projector Screen - The LED Kit

The LED BackLight Kit

Projection Screen LED KIT 2018 Version (135-inch Diagonal Screen, 16:9 Aspect Ratio)

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...

Home Theater Design – The Passive Subwoofer Amplifier

Home Theater Design – The Passive Subwoofer Amplifier

Designing a Home Theater - Home Theater Subwoofer Amplifier

When Do You Need A Passive Subwoofer Amplifier

A passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker.

The home theater system has a subwoofer output. but it’s a passive output. Meaning the output is not amplified.

So you need either use an active subwoofer (a subwoofer enclosure with an amplifier built-in) or a passive subwoofer amplifier.

Searching For A Subwoofer Amplifier

The criteria for a subwoofer amplifier is pretty simple. It needs to be strong enough to power the sub-woofers and something that could be triggered on and off from the home theater system – removing the need for yet another remote control.

And of course a subwoofer amplifier that’s not too expensive would be nice.

When doing the searches for a subwoofer amplifier many of the search results will be for 12 volt car stereo amplifiers – not exactly what you’re looking for. lol

One good way to get search results to be more relevant is by searching for 8ohm subwoofer amplifier. Typical house speakers are 8ohm and car speakers are 4ohm.

The Passive Subwoofer Amplifier I Chose

The subwoofer amp I chose is the OSD Audio SMP250; 250-Watt Single Channel Subwoofer Power Amplifier.

I chose this amplifier mainly because of the wattage, the 12V trigger and the price.

Two of the three criteria ended up not being a factor. But they where what I was looking for when I first started my search.

Designing a Home Theater - Home Theater Subwoofer Amplifier

OSD Audio SMP250; 250-Watt Single Channel Mono High Current Class A/B Subwoofer Power Amplifier with Front Panel Phase Switch, Adjustable High-Cut Filter and Volume Knob

Tips For This Amplifier

The subwoofer amplifier works great. During this experience I learned quite a few things that you should also keep in mind.

The Subwoofer Amplifier’s 12 Volt Trigger

The 12 volt trigger is what the sub amp uses to detect when it should turn on. The trigger “listens” for sound coming to it and turns the amp on when it things it needs to turn on. That way it would turn itself on/off without the need for a remote control.

The trigger did technically work the way it should have. The amplifier did turn on when it detected that it needed to.

But when it did, the subwoofer made a really loud popping sound when the amplifier turned on.

Tech support even sent me a replacement amp but the new amp also made the popping sound.

I instead changed the subwoofer amp trigger to be on all the time, which turned out perfect.

The amp does go into stand-by mode when it doesn’t receive an audio signal. Then when it comes out of stand-by, it doesn’t make a popping sound!

250 Watts

This one is a good problem, in a way. lol

One of the reasons I chose this amplifier was because of the wattage. Since the subwoofers are 300 watt speakers, I wanted an amplifier strong enough to power them.

Honestly, I could have gone with a less powerful amplifier and the bass would have been fantastic.

This amplifier was more than enough to power my subwoofers. There is a level volume control on the back of the amp which I set to about half way and the subs basically shake the house.

This is a Mono Subwoofer Amplifier

This is a mono subwoofer amp, meaning there’s one output channel. And I have two subwoofers.

The subwoofer amplifier manual does have a workaround. It says the speakers will get the power they need if they’re connected in parallel.

So that’s what I did. Basically, I have the speaker wire for both subwoofers squished into one banana plug.

Make Sure To Get Banana Plugs

When there are only a couple of wires going to the back of your equipment the wires are totally manageable.

But when you have multiple speakers, things can get messy in a hurry. In this case, there were 9 sets of speaker wire along with all the HDMI cables.

Banana plugs help make the wire management manageable.

The Banana Plugs I Chose

These banana plugs are great, they make the install much easier and cleaner.

They really helped with getting both subwoofer cables into a single port.

Mediabridge Banana Plugs – Corrosion-Resistant 24K Gold-Plated Connectors – 12 Pair/24 Banana Plugs

Designing a Home Theater - Home Theater System - Banana Plugs

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...

Home Theater Design – Choosing A Home Theater System

Home Theater Design – Choosing A Home Theater System

Designing a Home Theater - Home Theater System - Yamaha TS-R7810

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing.

The first thing you’ll need to figure out on your home theater system search is what features are important to you.

If you were like me, you don’t even know what features you’re looking for.

Hopefully, my research will help cut a few hours off your amplifier search.

*PLEASE NOTE, SOME OF THESE LINKS ARE AFFILIATE LINKS. THAT MEANS IF YOU CLICK ON ONE OF THE PRODUCT LINKS, WE’LL RECEIVE A SMALL COMMISSION AT NO EXTRA COST TO YOU. IT HELPS SUPPORT THIS BLOG AND ALLOWS US TO KEEP SHARING OUR CONTENT FOR FREE. AS AN AMAZON ASSOCIATE I EARN FROM QUALIFYING PURCHASES.

What I Was Looking For In A Home Theater System

For the surround sound system, my criteria list was pretty straight forward:

  • 5.1 surround sound
  • Enough HDMI inputs (since the home theater system was going to control the inputs)
  • a good enough wattage to get my attention

The home theater system is the heart of your theater setup. It controls all the video sources, so all the video signals pass through it.  Since the projector in my setup was both 4K and HDR capable, the amplifier needed to support both 4K and HDR.

Designing a Home Theater - Home Theater System - The Home Theater System Is The Heart Of The Home

Options For A Home Theater System

Dolby Digital Options

Dolby, THX or DTS

There are three different standards for a home theater system – Dolby, THX, and DTS.

By far, the most common standard of the three is Dolby digital. I wasn’t able to figure out the differences between the three – other than THX and DTS usually cost more.

Because THX and DTS cost more, the choice, in the end, was more about which flavor of Dolby to get.

Which flavor really depends a lot on the speaker budget – and how many speakers can fit into that budget.

What Flavor Of Dolby?

I had always heard of Dolby Digital 5.1 but never really knew what the numbers meant. All I knew was that 5.1 was a good surround sound system.

In my search for a surround sound system, I finally understood the numbers.

A 5.1 system means there are 5 surround sound speakers and 1 subwoofer.
The 5 surround sound speakers would be:

  • the center speaker
  • left and right front speakers
  • left and right rear speakers

In our days, there are a lot of systems that are Dolby Digital 7.1 surround sound. The difference in the 7 in 7.1 surround sound system and the 5 in 5.1 is the additional two back speakers.

When shopping for speaker systems, you’ll come across a third number, like 5.1.2 or 7.1.4. That third number is the number of in-ceiling speakers, also called presence speakers.

The latest iteration of Dolby is Dolby Atmos. The way they describe it is that is object-oriented sound. Which means Atmos does a better job of determining what sound should go pushed to what speaker.

Below is a table with the different speaker layouts.



The Different Dolby Speaker Layouts

Speaker
5.1
5.1.2
5.2.2
7.1
7.2
7.1.2
Center Speaker
X
X
X
X
X
X
Left Front Speaker
X
X
X
X
X
X
Right Front Speaker
X
X
X
X
X
X
Left Rear Speaker
X
X
X
X
X
X
Right Rear Speaker
X
X
X
X
X
X
Second Left Rear Speaker



X
X
X
Second Right Rear Speaker



X
X
X
Ceiling Speaker Count
0
2
2
0
0
2
Subwoofer Count
1
1
2
1
2
1

If you want more details about the different Dolby speaker setups, below is a great link from Dolby. (Fair warning it gets pretty speaker geeky)

Dolby Atmos Speaker Setup Guide

Other Features Available

There are a lot of features available on home theater systems. But most of them aren’t a factor for a dedicated home theater system.

In my case, the surround sound system was only for the movie theater. And really only for the audio from a TV, DVD, NetFlix, etc…

Features like multi-zone, Bluetooth streaming, wifi streaming, and network audio playback are available. But none of those mattered in my setup at all.

The Home Theater System I Chose

Like I said earlier, your speaker budget will be the driving force behind your home theater system decision.

In the end, I found a great price on a set of 7.2 speakers, so I knew I could start looking for a Dolby 7.2 home theater system.

The amplifier I ended up going with is the Yamaha TSR-7810 7.2-Channel Network Receiver, which I purchased online.

It had great reviews and more than enough features for my setup at a reasonable price.

The amplifier has 7.2 channel surround sound, DTS:X, Dolby Atmos, the 4K HDR passthrough and support for 3D. It met all the criteria from my list, and it was also a reasonable price.

Designing a Home Theater - Home Theater System - Yamaha TS-R7810
Designing a Home Theater - Home Theater System - Yamaha TS-R7810 - Back

Get The Same Home Theater System

Click To Get The Same Home Theater System - Yamaha TS-R7810

Yamaha TS-R7810 7.2-Ch x 95 Watts Networking A/V Receiver Same as RX-V781

Tips For This Home Theater System

Here are a few tips that’ll help your Yamaha amplifier sound it’s best.

Make Sure To Run The YPAO Test

The YPAO test made a significant improvement in my setup. I would definitely recommend running the test if you have a Yamaha home theater system that has YPAO.

The amp comes with a microphone that you plug into the front of the amp. All you need to do is center the microphone in the listening space and start the test.

Make sure you’re not standing between the microphone and any of the speakers while the test is being run. That way, you don’t interfere with the microphone picking up the speaker sounds.

Designing a Home Theater - Home Theater System - Yamaha TS-R7810 - YPAO Mic

When I ran my test, I placed the mic on the top of the center seat in the theater. Then I started the test and stayed out of the room until it was complete.

YPAO will do a few tests on the speakers and optimize the audio for the space.

I’d say there was a big difference in the surround sound quality after the test ran. Even a non-audiophile like me was able to tell the difference.

Enable The Enhancer Option

Sound quality is not always an easy thing to describe. But enabling the enhancer option on the amp gives the sound a nicer, deeper, fuller sound.

Something To Keep In Mind About Home Theater Systems

My past purchases for home theater systems have always included powered (active) subwoofers.

An active subwoofer is one that has an amplifier built-in, a passive subwoofer doesn’t.

When you’re dealing with a passive subwoofer, you’ll need to buy a separate amplifier to power the subwoofer.

That was a fact that escaped me when I was doing my research for a home theater system. I only figured it out when I installed the amplifier and speakers, and sadly, my subwoofers had no sound coming out of them.

After a few web searches, I found out I needed to buy a separate passive subwoofer amplifier.

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...

Home Theater Design – Home Theater Speakers

Home Theater Design – Home Theater Speakers

Designing a Home Theater - Home Theater Speakers - Front Speakers - The Projector Wall with in wall speakers

When you’re designing your home theater, it’s best to look at both, your amplifier and speakers at the same time.

Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on home theater speakers. For more details about the amplifier, make sure to check out the article in this series on the amplifier.

*PLEASE NOTE, SOME OF THESE LINKS ARE AFFILIATE LINKS. THAT MEANS IF YOU CLICK ON ONE OF THE PRODUCT LINKS, WE’LL RECEIVE A SMALL COMMISSION AT NO EXTRA COST TO YOU. IT HELPS SUPPORT THIS BLOG AND ALLOWS US TO KEEP SHARING OUR CONTENT FOR FREE. AS AN AMAZON ASSOCIATE I EARN FROM QUALIFYING PURCHASES.

What Was I Looking For In Home Theater Speakers

The initial search criteria was simple, quality speakers and a reasonable price.

After a lot of searching, I soon realized I needed to find a reasonable price above anything else. These things are expensive!

If money was no object, I would go with Klipsch speakers. But those were many thousands of dollars, way outa my budget.

Now back to the search criteria. They needed to be affordable, in-wall, and a strong enough wattage that I could feel the sound from them. I figured a couple of hundred watts would be in the right ballpark.

I wanted in-wall speakers because I liked the finished look it gives.

To me, having speaker enclosures hanging around the room doesn’t give it as much of a finished look.

The Speakers

I did a good amount of searching, but honestly, the prices I kept coming up with were knocking the wind out of my sails.

Then I came across a company called Acoustic Audio. They had sets of in-wall speakers that were very reasonably priced.

Now I’m sure these speakers wouldn’t compare to the high-end speakers I kept finding in my searches. But, at less than 1/10th the cost they were the right choice for me.

The speakers I chose are the Acoustic Audio HD728 7.2 Home Theater Speaker System. There is an HD726 model as well, which is the same amount of speakers, just smaller speakers with a bit less power.

I’m pleased with these speakers; they sound and look great.

One thing that they don’t mention on Amazon’s listing was the rotatable tweeters. All the tweeters rotate, to get high pitched sounds directed at the listener.

I have a few tips with these speakers that I’ll share. In the end, these speakers are great once you follow the tips.

The Speakers I Chose

The speakers are the Acoustic Audio HD728 in-wall home theater 7.2 surround 8 inch speaker system.

They work great for me, just follow the tips I have below and you are sure to have the same results!

Acoustic Audio HD728 in-Wall/Ceiling Home Theater 7.2 Surround 8″ Speaker System

Tips For These Speakers

I have a bunch of tips for these speakers. As I said, I really like these speakers, and the tweaks I used helped make this an even better purchase.

Don’t Judge The Speakers Until They Are In The Walls

When the speakers came in the mail, I did what most people do when they receive their speakers. At least I hope I’m not the only one that did this. 🙂

I felt like a kid on Christmas morning, I was dying to see what the speaker sounded like. So I ran to the movie theater and plugged them in without installing them in the walls.

It was a bit of a buzz kill – the speaker sounded like they were all tweet with no woof.

Luckily I didn’t act on impulse and return them. The thing to keep in mind with any speaker is they can only provide bass when there is some sort of air resistance. The speakers need an enclosure around them for air resistance.

In the case of in-wall speakers, they use the walls themselves to provide that resistance.

Once the speakers were in the walls, the mid-tones and deep basses came out, and the sound was great!

Home Theater Speakers – The Placement

The speaker placement took some time to figure out. Between the surround sound aspect of it and which speaker should go where it was a lot to put together.

Unfortunately, the speakers I bought don’t really specify which speaker is for what.

I did a lot of digging around in posts, forums, and reviews. With some process of elimination, I figured out where each speaker should go.

If you also buy one of the Acoustic Audio speaker systems, this will help you save hours on guesswork.

The Acoustic Audio speaker system I bought was the HD728. Acoustic Audio has several speaker packages, but they all seem to use the same speakers.

Here are the speakers the system came with and where I installed them.

(4) HD800 Front In-Wall Speakers – These are the rectangular speakers – I used them as the Front Left and Right speakers and the Front Left and Right presence speakers (in the ceiling)

(2) HD8 Rear In-Ceiling Speakers – The smaller round speakers with a round frame – I used these as the rear left and right surround speakers.

(1) HD6c Dedicated In-Wall Center Channel Speaker – The long rectangular speaker – it goes under the projector screen.

(2) HDS10 Dedicated 10-inch In-Wall Passive Subwoofers – The larger round speakers – Some posts said spreading the deep bass around the room makes the sound more immersive. So I put one in the bottom front right of the projector wall, and the other in the platform floor. Behind the back row of chairs.

I used the surround sound amplifier documentation a lot to figure out the speaker layout.

The layout I used is 5.2.2:

  • 5 surround sound speakers (Front left and right, back left and right and center)
  • 2 subwoofers (in the floor in the back and in the projector wall in the front)
  • 2 presence speakers (in the ceiling in the front, just a little in front of the front row of chairs)

Below are a couple of diagrams that show the speaker placement.

Designing a Home Theater - Home Theater Speakers - The Speaker Layout - Top View
Designing a Home Theater - Home Theater Speakers - The Speaker Layout - Front View

Best Bang For The Boom

Part of my theater design included a platform for the second and third rows. I figured I’d use the platform as an enclosure for one of the subwoofers. So I installed the back subwoofer in the platform behind the third row of seats.

That was a fantastic way to get a whole lotta boom out of that subwoofer! The entire platform (second and third row) shakes when that subwoofer kicks in.

If you have a platform in your theater, I’d recommend doing the same thing to get a better theater experience. It is better than going to the movies.

Designing a Home Theater - Home Theater Speakers - The Back Subwoofer

Buy Good Quality Speaker Wire

I read in many many links that a good speaker wire has a lot of impact on the speaker’s performance.

Inferior speaker wire will affect even the best speakers in the world.

The wiring that came with the speakers was incredibly thin wire. Do not use that wire.

Luckily I listened to the articles I read and ran 14AWG wiring to all the speakers.

My setup required me to crawl into the attic above the movie theater to run the speaker wires.

Going into crawl spaces is not my idea of fun. If I was going to into the crawl space, I was making sure that I was going to use the right speaker wire right off the bat.

Designing a Home Theater - Home Theater Speakers - Cable Matters 14 AWG CL2 in Wall Rated 100 feet Speaker Wire

The Speaker Wire I Bought

Cable Matters 14 AWG CL2 in Wall Rated Oxygen-Free Bare Copper 2 Conductor Speaker Wire (Speaker Cable) 100 Feet

In Ceiling/Wall Speakers Are Great But….

I loved the clean look of speakers in the walls and ceiling without the speaker boxes. For me, the boxes are eye-sores.

A gotcha with ceiling and wall speakers is where you install them. They need to be between studs, and that is not always possible.

In my case, I had studs that were right in the middle of where I was going to put the wall speakers. Both in the front and the back of the rooms.

My workaround for the front was to build a speaker enclosure around the projector screen.

In the end, it gave the wall a beautiful look, but of course, it was much more work than just making a hole for the speaker in the drywall.

I had read an Amazon review for the speakers that recommended making a plywood box and putting the box in the wall. They said the plywood gave much more depth to the speakers.

Ultimately, my speakers ended up being in plywood boxes, and the bass from the speakers is fantastic.

I keep telling myself it’s the plywood that made the difference. To feel better about having to build out the boxes.

For the back wall, I didn’t want to build out large boxes. What I did instead is make small boxes, and I angled them, so they didn’t look too strange. I also made a hole in the drywall to give the speakers more air space to work with.

Having them angled also directed the sound into the center of the room better.

The Front Speaker Enclosures

Here are the details for the front speaker enclosure, in case you’d like to do something similar for your setup.

The enclosure is constructed of 3/4″ OSB plywood, with 1/2 drywall covering it.

The Dividers

The front enclosure is one big box, that’s divided into three sections. That way, each speaker has its own air space.

I figured it was a good thing to do to prevent the speakers from interfering with each other.

The double gray lines show where I put the section dividers, which are also made of 3/4″ pieces of OSB plywood.

Designing a Home Theater - Home Theater Speakers - The Front Speaker Enclosure - Front View
Designing a Home Theater - Home Theater Speakers - The Front Speaker Enclosure - Top View

Speaker Enclosure For The Back Speakers

The boxes for the back were pretty simple. They also needed a box because the studs didn’t line up where I wanted to place the back speakers.

For the back speakers, they were butting up to the ceiling and the wall. Because of that, they only needed plywood for the face and the bottom.

The plywood for the face of the speaker is 12″ x 12″. The bottom of the box including the face is 6″ x 12″ x 11″

Here are some pics of the back speaker enclosure. Because there wasn’t enough air space created by the box, I cut out the drywall hidden behind the speaker box. It gave the speakers a little more space to work with.

Designing a Home Theater - Home Theater Speakers - The Back Speaker Enclosure - Front View
Designing a Home Theater - Home Theater Speakers - The Back Speaker Enclosure - Bottom View

A Modification To The Plastic Clips

One thing the manufacturer did skimp out on is the plastic clip that holds the speakers in place.

I ended up modifying the clips to make it easy for the clips to open and close.

Without the modification, the plastic clips can break when installing the speaker.



The Modification

Unmodified, the plastic clips catch the edging of the plastic speaker frame. If you continue to screw it in, the plastic where the screw head sits will break (ask me how I know that).

The modification is simple. Once done, you’ll be able to screw and unscrew the speakers without a problem.

It’s only a matter of removing the corner of plastic and angling it, so it directs the clip where to go.

Do that to each clip, on each speaker, and you’ll be all set.

Cut This Corner Out

Designing a Home Theater - Home Theater Speakers - Cut This Plastic Corner Of The Speaker

Choosing The Right Home Theater Speakers

I hope the information in this article helps you with your choice for home theater speakers.

I’d love to hear your thoughts. Go ahead and leave comments below.

Let me know if you have any questions or what you would do differently with your speakers.

Thanks!

More Home Theater Design Articles

Home Theater Design – Home Theater Remote Control

What To Look For In A Home Theater Remote ControlAlthough it may not have been in your Home Theater Design, you will need a home theater remote control. Setting up a home theater buries you in remotes pretty quick. It becomes a 3 or 4 remote task to do anything unless...

Home Theater Design – The Video Projector

What I Was Looking For In A Video ProjectorOne of the main choices when designing a movie theater (and potentially the most expensive) is the video projector. I was expecting to spend a good amount of money, to get a good projector. And hoping to get a 4K projector...

Home Theater Design – The Fixed Projector Screen

Selecting a fixed projection screen should be the next choice after which projector to buy. When designing a home theater, there is a whole lot of research and many choices that needed to be made. Not the least of which is which fixed projector screen to buy. Here...

Home Theater Design – The Passive Subwoofer Amplifier

When Do You Need A Passive Subwoofer AmplifierA passive subwoofer amplifier is usually needed when you have an in-wall subwoofer speaker. The home theater system has a subwoofer output. but it's a passive output. Meaning the output is not amplified. So you need either...

Home Theater Design – Choosing A Home Theater System

Like the projector and projector screen, there are many options for a home theater system. And just like the projector, the sky is the limit when it comes to pricing. The first thing you’ll need to figure out on your home theater system search is what features are...

Home Theater Design – Home Theater Speakers

When you’re designing your home theater, it's best to look at both, your amplifier and speakers at the same time. Each one affects the other, so researching them both at the same time will help you make the best choice for both.  This article will focus on...
